Processor & Chipset |
| Chipset Manufacturer |
Intel |
| Processor Socket |
Socket BGA-1283 |
Integrated Processor |
| Integrated Processor Manufacturer |
Intel |
| Integrated Processor Type |
Atom |
| Integrated Processor Model |
C2750 |
| Integrated Processor Core |
Octa-core (8 Core) |
Memory |
| Number of Memory Slots |
4 |
| Memory Form Factor |
SoDIMM |
| Maximum Memory Supported |
32 GB |
| Memory Standard |
DDR3-1600/PC3-12800 |
| Memory Standard |
DDR3-1333/PC3-10600 |
| Memory Technology |
DDR3 SDRAM |
| Memory Speed Supported |
1600 MHz |
| Memory Speed Supported |
1333 MHz |
I/O Controller |
| Controller Type |
Serial ATA/600 |
| Controller Type |
Serial ATA/300 |
Video |
| Onboard Video |
On-board Video Chipset |
| Graphics Controller Manufacturer |
ASPEED |
| Graphics Controller Model |
AST2400 |
Network & Communication |
| Gigabit Ethernet |
Yes |
I/O Expansions |
| Total Number of Expansion Slots |
1.0 |
| PCI Express Standard |
PCI Express 2.0 |
| Total Number of PCI Express Slots |
1 |
| Number of PCI Express x8 Slots |
1 |
Interfaces/Ports |
| Total Number of USB Ports |
4 |
| Number of USB 2.0 Ports |
2 |
| Number of USB 3.0 Ports |
2 |
| VGA |
Yes |
| Number of Network (RJ-45) Ports |
5 |
Onboard Interfaces |
| Number of SATA Interfaces |
6 |
| Total Number of Onboard USB Ports |
2 |
| Number of Onboard USB 3.0 Ports |
2 |
Physical Characteristics |
| Form Factor |
Mini ITX |
| Width |
6.8" |
| Depth |
6.8" |
Miscellaneous |
| Compatibility |
Supermicro SuperServers
1U System:
Supermicro SuperChassis
1U Chassis:Mini-iTX Chassis:
|
| Environmentally Friendly |
Yes |
